Model: SM-J400M
This tutorial for how to download Samsung 4 Files Firmware,for flashing, BL,AP,Cp,CSC,HOME etc. Jul 08, 2019 The instructions on download page said the download should contain 5 files: BL, AP, CP, CSC and HOMECSC, which I should add to the correct fields in Odin. How do I use this file to populate the 4 fields in Odin and select the CSC file? I want to do a clean install - I've already factory reset the phone and it hasn't solved the reboot loop issue.
Device Name: Galaxy J4
PDA: J400MUBSCCUE3
CSC: J400MOWMCCUE3
Region: COL
Country: Colombia
OS Version: 10
Changelist: 19180804
Bl Ap Cp Home_csc Download S6 Edge
Build Date: 2021/5/25
Download Bl+ap+cp+home_csc J7 Prime
INSTRUCTIONS (5 FILES)
Download Odin v3.13.3
Extract the firmware file you just downloaded. You should get 5 files:
AP (System &Recovery)
BL (Bootloader)
CP (Modem / Radio)
CSC_*** (Country / Region / Operator)
HOME_CSC_*** (Country / Region / Operator)
Add each file to it's respective field in Odin v3.13.3. Use CSC_*** if you want to do a clean flash or HOME_CSC_*** if you want to keep your apps and data. Reboot your phone in Download / Odin mode (make sure your device is off) with the following button combo: POWER + VOLUME DOWN + BIXBY Other options in case first option did not work or isn't possible.
Option 2 VOLUME DOWN + VOLUME UP than USB cable
Option 3 POWER + VOLUME DOWN + VOLUME UP
Option 4 POWER + VOLUME DOWN + HOME BUTTON
Option 5 (Note9) USB cable + VOLUME DOWN + BIXBY
Once in download mode, connect your phone to the PC, preferably using the original USB cable you got with your phone. Odin should detect your device and a BLUE box will show up with the COM port number. (Be sure, the SAMSUNG-drivers are installed on your PC!)
Do NOT tick any extra boxes. The only options to be ticked are F.Reset Time and Auto-Reboot.
Click the start button, wait for Odin to say 'PASS' in a GREEN box. Once the flash is complete, your phone will reboot, and you can disconnect your phone from the PC.
INSTRUCTIONS (1 FILES)
Download Odin v3.13.3
Extract the firmware file you just downloaded. You should get 1 file:
AP (System &Recovery)
Add MD5-file in AP-field in Odin
Reboot your phone in Download / Odin mode (make sure your device is off) with the following button combo: POWER + VOLUME DOWN + BIXBY
Other options in case first option did not work or isn't possible.
Option 2 VOLUME DOWN + VOLUME UP than USB cable
Option 3 POWER + VOLUME DOWN + VOLUME UP
Option 4 POWER + VOLUME DOWN + HOME BUTTON
Option 5 (Note9) USB cable + VOLUME DOWN + BIXBY
Once in download mode, connect your phone to the PC, preferably using the original USB cable you got with your phone. Odin should detect your device and a BLUE box will show up with the COM port number. (Be sure, the SAMSUNG-drivers are installed on your PC!)
Do NOT tick any extra boxes. The only options to be ticked are F.Reset Time and Auto-Reboot.
Click the start button, wait for Odin to say 'PASS' in a GREEN box. Once the flash is complete, your phone will reboot, and you can disconnect your phone from the PC.
